HRV 10" 3-Stage UV Whole House Water Filtration System

Help protect your household water supply with the HRV 3-Stage Whole-House UV Water Filtration System. Designed for residential and commercial applications, it combines two stages of sediment filtration with ultraviolet disinfection to treat water before it reaches taps and other outlets throughout the property.

The coarse and fine sediment filters help reduce suspended particles and cysts such as Giardia and Cryptosporidium. Water then passes through a stainless-steel UV chamber, where ultraviolet light helps inactivate disease-causing microorganisms without adding chemicals or changing the water’s taste, colour or odour.

The splash-resistant electronic controller displays the remaining lamp life and provides visual and audible warnings for lamp failure, low UV output and other system conditions. Its modular design supports future upgrades, while the single-ended lamp can be changed without draining the UV chamber.

Key Features

• Three-stage whole house water-treatment system

• Two stages of coarse and fine sediment filtration

• UV disinfection as the third treatment stage

• Helps reduce fine particles and suspended sediment, Giardia, and Cryptosporidium cysts

• Remaining UV lamp life display and visual and audible lamp

• Controller diagnostics, warnings, and status information

Specifications

• Stage 1: Coarse sediment filtration

• Stage 2: Fine sediment filtration

• Stage 3: Ultraviolet disinfection

• Electrical Supply: 90-265V / 50-60Hz

• Maximum Operating Pressure: 150psi

• Operating Temperature: 2-40°C

• Total Power Consumption: 23W

• UV Lamp Output: 20W

• Flow Rate (@16/mJ/cm³): 58.8L/min

• Flow Rate (@30/mJ/cm³): 30.4L/min

• Flow Rate (@40/mJ/cm³): 23L/min

• UV Chamber Dimensions: 89mm x 508mm (3.5" x 20")

• Controller Dimensions: 171.5mm x 92.1mm x 76.2mm (8.6" x 4.2" x 3.5")

• System Dimensions: 680mm (H) x 580mm (W) x 215mm (D)
